Tecnología central de Pultruded de la forma redonda no metálica de FRP que fortalece/de KFRP Rod CSM Φ2.0
Detalles del producto
material del kfrp
,Miembro de FRP
Miembro de fuerza central no-metálico de FRP/KFRP Rod CSM, KFRP Rod Φ2.0
Somos fabricante no-metálico/proveedor del miembro de fuerza central de FRP Rod en China, ofreciendo al miembro de fuerza de Pultruded FRP Rod para los cables ópticos de la fibra.
Especificaciones: (FRP redondo: ∮0.4-∮5.0)
| Propiedad | Valores |
| Resistencia a la tensión (Mpa) | ≥1100 |
| Módulo extensible (Gpa) | ≥50 |
| Fuerza flexural (Mpa) | ≥1100 |
| Módulo flexural (Gpa) | ≥50 |
| Alargamiento en la rotura (%) | ≤4 |
|
Coeficiente de la termal linear
extensión (- 30-80℃) (1/℃) |
<8*10-6 |
| Tolerancia del diámetro (milímetro) | el ±2% |
| Radio de doblez mínimo (milímetro) | 40*D |
| Densidad (g/cm3) | 2.05-2.15 |
| Prueba de flexión da alta temperatura (50D, 100℃, 120h) |
Ninguna oficina, grieta y
rotura |
| Prueba de flexión de la baja temperatura (50D, - 40℃, 120h) |
Ninguna oficina, grieta y
rotura |
| Torsión (±360°/m) | No desintegrado |
We develop and produce Flat FRP strength member for different application.
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
Cable Strengthen Core For Fiber Optical Cables Non-Metallic FRP Rod Central Strength Member CSM Basic Info Technique: Pultrusion Type: Themosetting Plastic Profiles Diameter Ranges: 0.40 mm to 5.00 mm HS Code: 70199090 Materials: Resin, E-glass Fiberglass, Agents, etc. Applications: Central or peripheral strength member for fiber optical cables Origin: Jiangsu, China Product Description: Non-metallic FRP Rod strength member, usually located at the center or the periphery of
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
